100 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Material | ABS Body+PC cover |
| Dimension | 34.2xH16.2mm |
| Click to view more | |
Product Details
Rated Power
1.0W
Light Color
RGB
Voltage
24V DC
Protection Level
IP68
Warranty
3 Years
Brand Name
R-Lite India
Product Code
CS-PX04
Description
- Using RGB Pixel Led Light signal transmission, manual/automatic addressing
- ABS flame retardant ABS production, more reliable installation performance.
- The installation structure is reasonable, use high-performance LED, good quality, uniform color, and higher brightness.
- Weatherproof PU glue is used for potting, high waterproof performance, high and low-temperature adaptability, and Good corrosion resistance.
- LIGHT SOURCE COLOR: Amber, Blue, CW(cold white), Green, Red, RGB(Multi Color), RGBW(Color Changing), W (4000K-4500K), WW(Warm white)
- CABLE: 2×0.35mm?+2×0.75mm? the cable of Male & Female connector
Specifications
| No. | ITEM NO. | LED QTY | LED TYPE | Light Color | Voltage | Wattage | Control | Remark |
| 1 | CS-PX04A-XX | 3PCS | 3535SMD | Single Color | DC12V | 0.72W | NO/OFF | 2-PIN Plug |
| 2 | CS-PX04A-RGB | 3PCS | 3535SMD 3in1 | RGB | DC12V | 0.72W | SPI | 4-PIN plug |
| 3 | CS-PX04A-DMX | 3PCS | 3535SMD 3in1 | RGB | DC12V | 0.72W | DMX512 | 4-PIN plug |
| 4 | CS-PX04B-XX | 4PCS | 3535SMD | Single Color | DC15V | 0.96W | On/Off | 2-PIN plug |
| 5 | CS-PX04B-RGB | 4PCS | 3535SMD 3in1 | RGB | DC24V | 0.96W | SPI | 4-PIN plug |
| 6 | CS-PX04B-DMX | 4PCS | 3535SMD 3in1 | RGB | DC24V | 0.96W | DMX512 | 4-PIN plug |
