100 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Country of Origin | India |
| Dimension | L50.5xW40xH14.5mm |
| Material | ABS + PC cover |
| Click to view more | |
Product Details
Voltage
24V DC
Protection Level
IP65
Warranty
3 Years
Brand Name
R-Lite India
Product Code
CS-PX02
Description
- Using RGBW Pixels LED Lights DMX512 Control signal transmission, manual/automatic addressing
- ABS flame retardant ABS production, more reliable installation performance.
- The installation structure is reasonable, use high-performance LED, good quality, uniform color, and higher brightness.
- Weatherproof PU glue is used for potting, high waterproof performance, high and low-temperature adaptability, and Good corrosion resistance.
- LIGHT SOURCE COLOR: Amber, Blue, CW(cold white), Green, Red, RGB(Multi-Color), RGBW(Color Changing), W (4000K-4500K), WW(Warm white)
- CABLE: 3×0.35mm?+2×0.75mm? cable of male & female connector
Specifications
| Optical | Lighting Source: 5050SMD LED | Chip Brand: EpistarCREELumileds |
| LED Quantity: 9PCS | Beam Angle120 | |
| Emitting Color: RGBW | Led life: >50000 hours | |
| Color Temperature: 1600~6500K | CRI: >80 Ra | |
| Electrical | Working Voltage: DC24V | Power Factor: > 0.85 |
| RatedPower: 1.8W | Electrical Class: III | |
| Construction | Shell Material: ABS Housing | Cover: Anti-ultraviolet PC mask |
| Dimensions: 50.5x40x17mm | Installation Method: Surface-mounted | |
| Control | Control Method: DMX512 | Gray level: 256x256x256 LV |
| Other | Ambient Temperature: -30~+50 | IP rating: IP68 |
Specifications
| No. | ITEM NO. | LED QTY | LED TYPE | Light Color | Voltage | Wattage | Control | Remark |
| 1 | CS-PX02-DMX3 | 6PCS | 3535SMD | RGB | DC12V | 1.2W | DMX512 | 5-PIN plug |
| 2 | CS-PX02-DMX4 | 9PCS | 3535SMD | RGB-W | DC15V | 1.8W | DMX512 | 5-PIN plug |
| 3 | CS-PX02-XX | 6PCS | 3535SMD | 1800~6500K | DC24V | 1.2W | On/Off | 2-PIN plug |
