100 Piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Shape | Round |
| Size | 85xH70mm |
| Warranty | 3 Years |
| Click to view more | |
Product Details
Country of Origin
India
IP Rating
IP65
Chip Brand
CREE/Epistar
Body Material
Aluminum housing cover
Brand Name
R-Lite India
Product Code
CS-PS02
Description
- Dmx Led Point Lights outdoor is die-casting aluminum lamp body, plastic-sprayed surface treatment.
- Light source adopts CREE/Epistar, can also specify other reliable brand, droop small high stability; For nearly 10 years of professional experience, unique drive technology, ensure the stability of each LED work.
- Waterproof design: special seal glue potting process, greatly reduced due to water damage of lamps and lanterns.
- Dmx Led Point Lights installation method: screw fixed directly, easy and convenient.
- Color effect, can choose the single color or RGB full color composite.
Specifications
| Optical | Lighting SourceSMD5050 3In1 LED | Chip BrandEpistartCREE |
| LED Quantity12 PCS | Beam Angle120 | |
| Emitting ColorSingle Color or RGB | Led life>30000 hours | |
| Color Temperature1600~6500K | CRI>80 Ra | |
| Electrical | Working VoltageDC24V | Power Factor> 0.90 |
| Power Consumption2.88W | Electrical ClassIII | |
| Construction | Shell MaterialAluminum Housing | CoverPCCover |
| Dimensions85*H70mm | ||
| Control | Lamp ControlDMX512TTLN/A | Gray level:256x256x256 |
| Other | Ambient Temperature-30~+52 | IP ratingIP65 |
Specifications
| No. | ITEM NO. | LED QTY | Light Color | Voltage | Wattage | Control | Dimensions | Remark |
| 1 | CS-PS02-DMX | 14PCS 5050SMD 3in1 | RGB | DC24V | 3.36W | DMX512 | 85*H70mm | 5-core plug |
| 2 | CS-PS02-RGBW | 14PCS 5050SMD 4in1 | RGBW | DC24V | 4.2W | DMX512 | 85*H70mm | 5-core plug |
| 3 | CS-PS02-RGB | 12PCS 5050SMD 3in1 | RGB | DC24V | 2.88W | TTL | 85*H70mm | 4-core plug |
| 4 | CS-PS02-12Q | 12PCS-5050 SMD | Single color | DC24V | 2.88W | N/A | 85*H70mm | 2-core plug |
| 5 | CS-PS02-18Q | 18PCS-5050 SMD | Single color | DC24V | 3W | N/A | 85*H70mm | 2-core plug |
| 6 | CS-PS02-3W | 3PCS 1W LED | Single color | DC24V | 3W | N/A | 120*H80mm | 2-core plug |
| 7 | CS-PS02-6W | 6PCS 1W LED | RGB | DC24V | 6W | DMX512 | 120*H80mm | 5-core plug |
